PCR thermal Cyclers
Thermax G-- Gradient Thermal Cycler
- Manual hot lead, high-strength mechanical buckle, not easy to wear.
- Small size, lightweight, suitable for various complex experimental environments.
- Unique rear air outlet design, multiple machines, can be placed side by side without difficult heat dissipation.
PRODUCT FEATURES
Fast ramping rate to 5 deegree/sec, saving valuable experimental time.
Stable temperature control: industrial semiconductor temperature control systems lead to accurate temperature control and great uniformity between wells.
Various functions: flexible program setting, adjustable time, temperature gradient, and temperature change rate, built-in Tm calculator.
Easy to use: Built-in graph text quick operation guide, suitable for operators with various backgrounds.
Dual Mode Temperature Control: Tube mode automatically stimulates the actual temperature in the tube according to the reaction volume, which makes the temperature control more accurate; The Block Mode directly displays the temperature of the metal block, applicable to the small volume reaction system, and takes shorter time in the same program.
SOFTWARE INTERFACE
Application Scenario
PRODUCT PARAMETER
| Model | Thermax G |
|---|---|
| Sample Volume & Consumable Type | 96-well×0.2 mL
(Full-skirted plate, Half-skirted plate, Non-skirted plate; 12x8 strip tubes, 8x12 strip tubes, Single tube) |
| Technology Program | Thermoelectric semiconductor technology |
| Monitor | Color Touch Screen (7 inch) |
| Screen Adjustability | Fixed |
| Block Temperature Range | 4°C - 105°C |
| Maximum Ramp Rate | 5°C/s |
| Temperature Distribution | <±0.2°C (55°C) |
| Gradient | 36°C max and accuracy is ±0.5°C |
| Temperature Accuracy | <±0.1°C (55°C) |
| Temperature Control Mode | Block mode, Tube mode |
| Ramp Rate Adjusting Range | 0.1 - 5°C |
| Program Capacity | Infinite |
| Maximum cycle | 99 |
| Time Increase/Decrease | 0.1 min ~ 9min 59s, Long PCR is available |
| Temperature Increase/Decrease | 0.1 ~ 9.9°C, Touchdown PCR is available |
| Auto Pause / Power-Off Protection | Available |
| 4°C Reservation | Available |
| Real-time Operation Status Display | Graph-text |
| Hot Lid Temperature Range | Room temperature +5 ~ 110°C |
| Hot Lid Temperature Display Accuracy | 0.1°C |
| Intelligent Hot Lid | Hot lid shuts off automatically when product is preserved at low temperature or program ends |
| Communication Interface | USB |
| Voltage Range | 100 ~ 240VAC, 50/60Hz |
| Output Power | 600W |
| Dimensions (D x W x H) | 280 x 187 x 190 mm |
| Net Weight | 7kg |
